P2.5 P3 P4 P5 P6 P8 P10 Large Outdoor LED Screen Manufacturer In China
- 10,000 + square meters of production workshop
- 200+ patented technologies
- Fully automated production line
- 24-hour online response
- IP65 waterproof and dustproof, high and low temperature resistant
- Lifetime free maintenance and upgrades
Outdoor LED Screen Application Scenarios
Outdoor LED display screens have the characteristics of high brightness, high refresh rate, high temperature resistance, low temperature resistance, strong wind resistance, WIFI, network connection, one-key upload and cluster management, etc. There are many application scenarios, the main application scenarios are as follows:
1. Stadiums & Events
Core requirements: strong light visibility, high-speed images, long-distance viewing
Solution:
Select P4-P8 high refresh rate (≥3840Hz) models to eliminate high-speed motion smears of athletes
Install anti-glare glass to reduce direct sunlight reflection (reflectivity <5%)
Case: Qatar world-cup
2. Transportation hub
Adaptation to extreme environments:
Airport terminal: P6-P10 screen, with automatic brightness sensing system (0-100% stepless adjustment)
Subway platform: shockproof structure design (passed EN 45545-2 fire protection certification)
Highway: ultra-bright P16-P20, visible distance up to 500 meters
3. Urban commercial buildings
Creative display solutions:Arc/special-shaped splicing (minimum bending radius 1.5m)
Transparent LED screen (transmittance ≥ 65%, used for glass curtain wall integration)
4. Harsh industrial environment
Special customization:
Offshore oil platform: IP68 + anti-salt spray coating (salt spray test 2000h)
Polar research station: -50℃ low temperature start + electric heating module
Desert mining area: anti-sand and dust filter (detachable and cleanable design)
5. Cultural tourism performance
High dynamic display:
HDR10+ high dynamic range (contrast ratio 1,000,000:1)
Synchronous control system (support Art-Net light and music linkage)
Outdoor LED Screen Series
Redefining Outdoor Vision with Pixels
- Massive Reach: High-traffic locations boost brand awareness instantly.
- Attention-Grabbing: Vibrant videos & animations captivate audiences.
- Agile & Efficient: Real-time content updates for timely campaigns.
- Tech-Driven: Modern digital display enhances brand prestige.
- Durable & Reliable: Weatherproof & heat-resistant
- Eye-Catching Tech Appeal: Transparent display with dynamic content enhances brand premium image.
- Natural Light-Friendly: Maintains building visibility & daylight, ideal for storefronts & glass facades.
- Space-Saving Design: Installs directly on glass, no bulky structures needed.
- 24/7 Impact: Seamless by day
- Immersive Visuals: Ultra HD display creates captivating experiences
- Maximum Exposure: Dynamic content grabs attention 24/7
- Smart Flexibility: Supports multi-zone/real-time content updates
- Smart Control: Remote content management and multi-zone display capabilities
- Proven Durability: energy efficiency and long lifespan
- Visual Dominance: Ultra-bright display visible from 200m+
- Prime Visibility: 100,000+ daily exposures at key urban locations
- Smart Control: Cloud-based scheduling & real-time updates
- Brand Elevator: Premium digital medium boosts corporate image
- Modular Flexibility: Customizable sizes for versatile installations
- Ultra Smooth Display: 3840Hz refresh rate for flicker-free viewing
- Energy Efficient: Low power consumption & 50,000hrs lifespan
- Seamless Integration: Millimeter-level precision for perfect alignment
- Plug & Play: Rapid deployment for temporary events
- Portable Design: Flight-case structure for easy transport
- Universal Compatibility: Fits various rental scenarios
- Full Support: On-site technical assistance guaranteed
Classification of outdoor LED screen installation methods
The installation methods of outdoor LED screen vary according to the installation environment. The commonly used installation methods are as follows：
-
Column LED ScreenColumn LED display screens usually have single columns and double columns. The columns are fixed from the ground, and then the screen is fixed in the middle or top of the columns.
Usually used in squares advertising LED screens, highway information screens -
Wall-mounted LED displayBy welding the steel frame structure on the wall, the outdoor LED display screen is installed and fixed on the surface of the steel frame structure, such as the outer wall of shopping malls, office buildings, government office buildings, and schools.
-
Suspended LED displaySuspension installation is required in some specific installation environments, such as Traffic LED screens（ Train stations and terminal LED screens, stage LED screens, Anti-sway dampers must be used and the dynamic load factor must be ≥ 1.5
-
Mobile LED displayMobile LED display screens meet the needs of temporary applications and emergencies, and are widely used in traffic guidance, mobile advertising vehicles and outdoor rental LED screens.
-
Embedded LED ScreenEmbedded installation can Integrate design with building curtain wall, save space and looks more beautiful.
It is more convenient and safer to maintain from inside the building.
-
Floor installationOutdoor LED Posters are usually installed on the ground, located on both sides of the road or around bus stops.To ensure the safety of the concrete platform height ≥ 0.5m and pre-buried grounding wire
Commonly Used Outdoor LED Screen Cabinets
Sheet Metal Cabinet
Advantages:
- High Durability: Metal construction resists impacts in industrial settings.
- Cost-Effective: Lower processing costs vs. alternative materials.
- Customizable: Easily bent/welded for diverse size requirements.
Disadvantages:
- Heavy Weight: Less portable than aluminum enclosures.
- Corrosion Risk: Requires surface treatment.
- Lead Time: 7-15 days for complex structures.
Die-casting Aluminum Cabinet
Advantages:
- Ultra-Lightweight: 40% lighter than steel (20-25kg/m²).
- Monolithic Structure: Die-casting precision ±0.2mm.
- Thermal Management: 200W/(m·K) conductivity.
- Corrosion-Resistant: Natural oxide layer withstands 1000h salt spray.
- Rapid Installation: Modular design improves 50% assembly speed.
Disadvantages:
- High customization cost: Die-cast aluminum requires mold development, so the high mold cost makes customization impractical.
- High Initial Cost: $10,000-100,000 mold development.
- High material cost: Compared with other sheet metal materials, aluminum is relatively expensive.
Flip Cover Cabinet
Flip cabinet can be single-sided or double-sided.
The cabinet of the double-sided LED screen can be made of sheet metal or aluminum.
It can meet the specific installation places that require double-sided LED screen.
The thickness of an independent double-sided LED display is almost half of that of two single-sided LED displays.
Which is more beautiful and relatively easier and faster to install.
Features and Benefits Of Top Shine Outdoor LED Screen
With its unique structural design and advanced technology and production strength, it can achieve excellent performance in various harsh environments. The following is a systematic description of its core advantages:
Wide operating temperature range: -40℃~60℃ stable operation (Arctic version can be extended to -50℃)
Waterproof and dustproof: IP65/IP68 protection level (can withstand high-pressure water gun washing)
Corrosion resistance: 316L stainless steel fasteners + nano coating (passed 3000h salt spray test)
Wind pressure resistance: 12-level typhoon (wind tunnel test ≥ 60m/s)
Shockproof design: vibration test before leaving the factory
Fireproof safety Material flame retardant:
PCB substrate: FR-4 V0 grade
Cable: LSZH low smoke zero halogen
Brightness 5000-12000cd/m² Clearly visible under direct sunlight
Refresh rate ≥3840Hz (upgradable to 7680Hz) High-speed picture without ghosting
Color gamut coverage 92% NTSC (ΔE≤3) Comparable to professional monitors
Viewing angle Horizontal/vertical 160° Wide-angle viewing without color cast
Computer software and APP control WIFI, USB, network cable one-click upload
Thousand-screen cluster control (support TCP/IP, 4G,)
Timer power on/off + playlist preset
Front/Real Maintenance Options
Top Shine Outdoor LED Screen Production Process and Quality Control
Control point Standard Testing equipment
Solder paste thickness 80-120μm 3D SPI detector
Patch accuracy ±0.025mm High-power optical AOI
Reflow curve Peak 245±5℃ Temperature curve tester
Negative pressure leak detection (-50kPa pressure difference for 10 minutes)
Rain test (IP65: 12.5L/min/m²×30min)
High temperature and high humidity: 60℃/95%RH (accelerated equivalent to 3 years)
Dynamic aging: full-screen switching of red, green, blue and white (1Hz frequency)
Point-by-point correction system:Brightness uniformity: ≤3% (using CCD imaging colorimeter)
Color consistency: Δu’v’≤0.003
Dynamic test:Refresh rate detection: ≥3840Hz (oscilloscope capture signal)
Vibration test: 5-500Hz/3 axes for 30 minutes each (IEC60068-2-6)
Drop test: 1.2m height, 6-sided free fall (ISTA-3A)
Low temperature start: Lights up after 4 hours of cold soaking at -40℃
Dust test: 8 hours of sand blowing (wind speed 15m/s)
Quanlity control And Test Equipment
- Test Equipment
- Data Sheet
- Details
Top Shine test equipment
Details
Related Product
Outdoor LED Screen Build Skyline-Defining Visual Spectacle
24/7 Reliability for Saper Journeys
- 20-30cm clearance for module replacement
- 80-120cm for full cabinet access
3840 and 7680Hz (E-Sports Grade) eliminates flicker for 4K/8K video capture. Standard models: 1,920Hz.
We usually have stock of the Outdoor LED screen modules, 7-15days for standard outdoor LED screen. 15-30 days for custom models.
Yes. Our certified installers cover 50+ countries.
